Lithium Ion Battery Cathode Electrode Aluminum Foil

Short Description:

The battery Aluminum foil is become more and more popular in the new energy in the past 8 years all over the world ,especially in China and Europe.

Lithium ion battery aluminum foil must be produced using optimal aluminum alloys for specific applications. Zhejiang New Aluminum Tech foil produces high -performance ,high-quality lithium ion battery foils for applications such as automotive and electronic device usage,from alloys carefully chosen for those specific demands



Product Detail

Product Tags

Details

图片 1

Zhejiang New Aluminum Technology Co Ltd is a leading marketer and supplier of high-performance aluminum foil rolls for battery manufacturing. Aluminum has been extensively used in recent years as a cathode foil in the manufacturing of lithium-ion batteries. Notable applications include consumer electronics and power tools, to Hybrid and Electric Vehicles. Our product line includes high-purity etched Al foil and battery-grade foils made from various alloys 1235, 1070, 1050, 1060 from the thickness 0.01mm to 0.035mm

sdf

 The characteristics for the Battery aluminum foil :

·    Excels in foil flexibility

Due to its flexibility, this foil is resistant to the expansion and contraction of battery at the time of charge/discharge.

·    Good in smoothness on either side

The active material to provide the functionality of battery can be applied uniformly.

·    Small in foil thickness variation

Due to its small thickness variation, the coating thickness variation of active material can be suppressed.

To raise the output power, the HEV battery has a thinner active material layer than the commercial batteries.

The smaller the foil thickness variation, the smaller can be made the thickness variation of the active material.

This advantageous property of our product has been highly appreciated by every automotive battery manufacturers, and is often a decisive factor in accepting orders.

Name

Aluminum Foil For Lithium Ion Battery

Alloy-temper

1060 1070 1235 O /H18

Thickness

0.01- 0.03mm  (tolerance:±5%)

Width and tolerance

300- 1200 mm (tolerance:± 1.0mm)

Weight

200 - 500kg per roll coil (or customized)

Surface quality

Free of black spot, line mark, creases, clean and smooth, no corrosion stains, wrinkles, and fish tails. Surface quality has to beuniform and no chatter marks.

Core material

Steel / aluminum

Core ID

Ф76mm, Ф150mm (±0.5mm)

Packaging

Fumigation free wooden cases(keep us informed if any special requests)

Tensile Strength(Mpa)

》190 MPa (according to thickness)

Elongation %

≥2%

Wettability

A  grade

Surface wetting tension

≥32 dyne

Application

for battery case of new energy, mobile phone and digital products

Deliver time

within 20 days after getting the original LC or 30% deposit by TT



Product specifications and parameters(thickness:0.010-0.030mm)

Item

Standard 1

Standard 2

hardness

H18

H18

width

Standard width ±1mm

Standard width ±1mm

Thickness

0.016±0.002 mm

0.012±0.002mm

areal density

42~46g/ m2

30~34g/m2

With transverse surface density uniformity

≤0.003 g/ 40×40 mm

≤0.003 g/ 40×40 mm

The same volume of vertical surface density uniformity

≤0.03 g/ 400×40 mm

≤0.03 g/ 400×40 mm

High temperature oxidation resistance (200°C*30min)

No oxidation

No oxidation

Connect no

<2

<2

Chemistry content(Al)

>99.45%

>99.45%

extensibility

<0.5%

<0.5%

Normal temperature Tensile strength kgf/mm2

>180

>140

After 1200C baking 1h, Tensile strength kgf/mm2

>160

>120

Coating performance

Aluminum foil with uniform tension on both sides, slurry coating uniformity

Quality Guarantee

We have strictly quality control system from aluminium ingot to finish aluminium roll products, and test all products before packing,just in order to make double sure that only qualified product will be delivery to clients  as we know even if little problem by us in our factory maybe lead to a  big trouble for clients when they get .If customer need ,we can apply the SGS and BV inspection when producing or loading.

sdf

Application

Power battery shell, connector, Pack box for power battery, power battery for the compartment, pouches of lithium ion battery, battery cell.
